Key Features:
- Line Interactive UPS with simulated sinewave output
- Excellent microprocessor control guarantees high reliability (Internal self-diagnostic technology)
- Boost and buck AVR for voltage stabilization (wide input range with two boost and one buck control)
- Auto restart while AC is recovering
- Cold start function
Model: GXK-1200-C
Capacity (VA/Watts): 1200 / 720
INPUT:
- Voltage: 220/230/240Vac
- Voltage Range: 140~300Vac
- Frequency Range: 50/60Hz (auto sensing)
OUTPUT:
- AC Voltage Regulation (Batt. Mode): ±10%
- Frequency Range (Batt. Mode): 50/60Hz ±1 Hz
- Transfer Time: Typical 4-8ms
- Waveform (Batt. Mode): Simulated Sinewave
BATTERY:
- Battery Voltage: 24Vdc
- Battery Type & Number: 12 V / 7Ah x 2
- Typical Recharge Time: 4~6 hours recover to 90% capacity
INDICATORS:
- LED Display (LED version): AC Mode, Battery Mode, Overload, Fault
- LCD Display (LCD version): AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, and Battery Low
PROTECTION:
- Full Protection: Short circuit, Overload, Overcharge, and overdischarge protection
ALARM:
- Battery mode: Sounding every 10 seconds
- Low Battery: Sounding every second
- Overload: Sounding every 0.5 second
- Battery Replacement Alarm: Sounding every 2 seconds
- Fault: Continuously sounding
MANAGEMENT:
- Communication port: USB or RS232 (Supports Windows 2000/2003/XP/Vista/2008, Windows 7, Linux, Unix, and MAC)
OPERATING ENVIRONMENT:
- Humidity: 0-90 % RH @ 0- 40°C (non-condensing)
- Noise Level: Less than 55dB
PHYSICAL:
- Approx. Dimension D * W * H (mm): 289101142
- Approx. Net Weight (kgs): 7.8
