الوصف
Key Features:
- Line Interactive UPS with simulated sinewave output
- Excellent microprocessor control guarantees high reliability (Internal self-diagnostic technology)
- Boost and buck AVR for voltage stabilization (wide input range with two boost and one buck control)
- Auto restart while AC is recovering
- Cold start function
Model: GXK-1000-C
Capacity (VA/Watts):
- Input Voltage: 220/230/240Vac
- Voltage Range: 140~300Vac
- Frequency Range: 50/60Hz (auto sensing)
Output:
- AC Voltage Regulation (Batt. Mode): ±10%
- Frequency Range (Batt. Mode): 50/60Hz ±1 Hz
- Transfer Time: Typical 4-8ms
- Waveform (Batt. Mode): Simulated Sinewave
Battery:
- Battery Voltage: 24Vdc
- Battery Type & Number
- Typical Recharge Time: 6~8 hours recover to 90% capacity
Indicators:
- LED Display(LED version): AC Mode, Battery Mode, Overload, Fault
- LCD Display(LCD version): AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, and Battery Low
Protection:
- Full Protection: Short circuit, Overload, Overcharge, and overdischarge protection
Alarm:
- Battery mode: Sounding every 10 seconds
- Low Battery: Sounding every second
- Overload: Sounding every 0.5 second
- Battery Replacement Alarm: Sounding every 2 seconds
- Fault: Continuously sounding
Management:
- Communication port: USB or RS232 (Supports Windows 2000/2003/XP/Vista/2008, Windows 7, Linux, Unix, and MAC)
Operating Environment:
- Humidity: 0-90 % RH @ 0- 40°C (non-condensing)
- Noise Level: Less than 45dB
Physical:
- Approx. Dimension D * W * H (mm): 314130175
- Approx. Net Weight (kgs): 7.2
